Datasheet: 0570-2004-04 (BEL Fuse)

LINE FILTER INDUCTORS



Download: PDF   ZIP
BEL Fuse
defining a degree of excellence
Corporate Office
Bel Fuse Inc.
198 Van Vorst Street, Jersey City, NJ 07302-4496
Tel: 201-432-0463
Fax: 201-432-9542
E-Mail: BelFuse@belfuse.com
Internet: http://www.belfuse.com
Far East Office
Bel Fuse Ltd.
8F/8 Luk Hop Street
San Po Kong
Kowloon, Hong Kong
Tel: 852-2328-5515
Fax: 852-2352-3706
European Office
Bel Fuse Europe Ltd.
Preston Technology Management Centre
Marsh Lane, Preston PR1 8UD
Lancashire, U.K.
Tel: 44-1772-556601
Fax: 44-1772-888366
T206
LINE FILTER INDUCTORS
MECHANICALS
Part Number
Date Code
0.198(5.00)
0.397(10.00)
Suggested PCB
Mounting Holes
0.397(10.00)
0.595(15.00)
0.05(1.1)
+/- 0.004(0.01)
0.595(15.00)
1
2
4
3
Bel
0.159(4.00)
0.028" sq.
0.70(17.65)
0.793(20.00)
0.515(13.00)
Bottom View
Dimensions are in inches(mm).
Dimension tolerance is equal to +/-
0.01(0.25)
unless otherwise stated.
1
2
3
4
0570-2004-01
0570-2004-02
0570-2004-03
0570-2004-04
0570-2004-05
0570-2004-06
0570-2004-07
10
20
30
50
75
100
150
2.0
1.5
1.0
0.75
0.60
0.50
0.50
93
93
93
95
87
85
88
35
70
100
200
200
210
300
% Of Initial
Inductance
At Rated
Current
Typ
Inductance
(uH) +/- 15%
Rated DC
Current
(ampheres)
Part
Number
DCR
(milliohms)
Max
ELECTRICALS
@ 25
o
C.
SCHEMATIC
Bel offers a series of line inductors designed to assist
in eliminating or reducing noise transmission in AC
or DC circuit applications. For example, these noise
suppression chokes are superior output
inductors when used in a switch mode power supply.
Our inductors are packaged in a compact, rigid vertical
case with "set" terminal pins to simplify mounting on
computer boards in microcomputer applications.
* Excellent Linear Magnetic
Characteristics.
* Operating Temperature Range
0
o
C to 70
o
C.
* A Toroid core to maintain
reduced flux leakage.
* Excellent vibration resistance.
TM0049
