0475-0100-50 (BEL Fuse) - Standard 5 Tap, Passive

defining a degree of excellence

Corporate Office

Bel Fuse Inc.
198 Van Vorst Street, Jersey City, NJ 07302-4496
Tel: 201-432-0463
Fax: 201-432-9542
E-Mail: BelFuse@belfuse.com
Internet: http://www.belfuse.com

Specifications subject to change without notice.

Far East Office

Bel Fuse Ltd.
8F/8 Luk Hop Street
San Po Kong
Kowloon, Hong Kong
Tel: 852-2328-5515
Fax: 852-2352-3706

European Office

Bel Fuse Europe Ltd.
Preston Technology Management Centre
Marsh Lane, Preston PR1 8UD
Lancashire, U.K.
Tel: 44-1772-556601
Fax: 44-1772-888366

Cat 14-R3

Transfer molded for better reliability
Compatible with ECL & TTL circuits
Terminals: Electro-Tin plate phosphor bronze
Performance warranty is limited to specified parameters listed

5 TAP 7 PIN SIP

PASSIVE DELAY MODULES

.125

.60 + .01

.80 Max

.255 Max

.10 Typ

.020

.018

.012
.008

.20 Max

.120 Min

50% Levels
10%-90% Levels
+ 10%
10K Megohms Min.
50 Vdc
-55

C to +125

100 PPM/

C Max.

3 x Trout or 5 ns W.I.G.
60%

Delay Measurement
Rise Time Measurement
Distortion
Insulation Resistance @ 50 Vdc
Dielectric Withstanding Voltage
Operating Temperature Range
Temperature Coefficient of Delay
Minimum Input Pulse Width
Maximum Duty Cycle

Part Numbers

5 + 0.5 ns

10 + 1.0 ns
20 + 1.0 ns
30 + 1.5 ns
40 + 2.0 ns
50 + 2.5 ns
60 + 3.0 ns
70 + 3.5 ns
80 + 4.0 ns
90 + 4.5 ns

100 + 5.0 ns

5 + 0.5 ns

10 + 1.0 ns
20 + 1.0 ns
30 + 1.5 ns
40 + 2.0 ns
50 + 2.5 ns
60 + 3.0 ns
70 + 3.5 ns

2.0 ns

3.0 ns
6.0 ns
9.0 ns

12.0 ns
15.0 ns
18.0 ns
21.0 ns
24.0 ns
27.0 ns
30.0 ns

2.0 ns

3.0 ns
6.0 ns
9.0 ns

12.0 ns
15.0 ns
18.0 ns
21.0 ns

0.6 Ohms
0.6 Ohms
0.8 Ohms
1.2 Ohms
1.8 Ohms
2.3 Ohms
2.5 Ohms
3.5 Ohms
4.2 Ohms
4.5 Ohms
5.2 Ohms

0.7 Ohms

1.0 Ohms
1.5 Ohms
2.5 Ohms
4.0 Ohms
5.0 Ohms
5.5 Ohms
6.0 Ohms

Electrical Characteristics

Ein
Trin
PW
PP

Pulse Voltage
Rise Time
Pulse Width
Pulse Period

1 Volt Typical
2.0 ns (10%-90%)
3 x Total Delay
4 x Pulse Width

Test Conditions @ 25

Notes

Out 7

In 2

Gnd 1

1 + 0.3 ns

2 + 0.4 ns
4 + 0.6 ns
6 + 1.0 ns
8 + 1.5 ns

10 + 1.8 ns
12 + 2.0 ns
14 + 2.0 ns
16 + 2.0 ns
18 + 3.0 ns
20 + 3.0 ns

1 + 0.3 ns

2 + 0.4 ns
4 + 0.6 ns
6 + 1.0 ns
8 + 1.5 ns

10 + 1.8 ns
12 + 2.0 ns
14 + 2.0 ns

bel

(DC)

(P/N)

3 4 5 6

50 Ohms
50 Ohms
50 Ohms
50 Ohms
50 Ohms
50 Ohms
50 Ohms
50 Ohms
50 Ohms
50 Ohms
50 Ohms

100 Ohms
100 Ohms
100 Ohms
100 Ohms
100 Ohms
100 Ohms
100 Ohms
100 Ohms

0475-0005-50
0475-0010-50
0475-0020-50
0475-0030-50
0475-0040-50
0475-0050-50
0475-0060-50
0475-0070-50
0475-0080-50
0475-0090-50
0475-0100-50

0475-0005-01
0475-0010-01
0475-0020-01
0475-0030-01
0475-0040-01
0475-0050-01
0475-0060-01
0475-0070-01

Total Delay

Rise Time

Tap-Tap Delay

Part Number

Impedance + 10%

DCR

Maximum

Other Delays and Impedances Available

Consult Sales
